PHONE FEATURES



Support 2 account lines, hotline

Support calls holding, calls waiting and calls transfer

Call transfer (blind turn, turn)

Caller id, redial, mute, don't disturb

Auto answer, conference

Speed-dial, SMS, voicemail

Message lamp, the state signal, the volume control

IP direct dial

Custom ring tone

Phonebook search/ import /export(300), black list

Call records: dial calls/received calls/miss calls /

Friendly user interface

Support one key quit menu(button c)

Support one key to view version number and network state

Support Hardware diagnostics

Multi-Language

Programmable keys



ADVANCED FEATURES



Xml phonebook search and import, help users quickly find number and one key to call

Enterprise phonebook

LDAP phonebook

Fuzzy search

Customizable home screen

Compatible with the mainstream IP PBX, as: Broadsoft/Avaya/Asterisk

Intercom, paging

Anonymous calling, anonymous reject

Dial plan, call immediately.

AUDIO FEATURES



Wideband encoding: G.722

Narrow band encoding: G. 711.μ/A, G723.1, G.729AB

Support VAD, CNG, AEC, PLC, AJB, AGC, such as audio processing ribbon coding

Full duplex speaker, with automatic echo elimination (AEC)



NETWORK FEATURES



Support SIP v1(RFC2543), v2(RFC3261)

Support DNS-SRV（RFC3263）

Support STUN

3 DTMF model: In-band, RFC2833, SIP INFO

Support the proxy server and point to point connection mode

Network model: static, DHCP, PPPOE

Support bridge and router model

Support TFTP/DHCP/PPPOE terminal

Support DNS client, built-in NAT/DHCP service

Login, logout in the web page



CONFIGURATION MANAGER



Support FTP/TFTP/HTTPS automatic configuration

Support 3 configuration models: web page, phone and auto provision

· Support TR069(choice)

Load default setting, capture package and system log export
